High Clarity & Precision
Biocompatible Material
Thermal Stability
Technical Specifications
Parameter Value
Recovered Wall .008" to .015"
Expanded ID (min) .054" to .425"
Ratio 1.3:1 to 2:1
Shrink / Grow 5% or less (length)
Stocked Items
SKU# Expansion Min. Recovery Max. Min Length (IN)
FEP001 0.054 0.034 60
FEP002 0.063 0.039 60
FEP003 0.093 0.058 60
FEP004 0.125 0.078 60
FEP005 0.188 0.115 60
FEP006 0.215 0.139 60
FEP007 0.250 0.155 60
FEP008 0.275 0.172 60
FEP009 0.300 0.187 60
FEP010 0.375 0.234 60
Customizable Services
Cross-section diagram showing multiple catheter layers including heat shrink fusing sleeve, outer jacket, braid, PTFE liner and mandrel.
Precise customization to expanded ID, recovered ID, recovered wall and cutting to custom lengths.
